HPE Series
HPE JL309A
- Product description: HPE JL309A _100GBASE-SR4 QSFP28 850nm 100m DOM MPO-12/UPC MMF Optical Transceiver Module_liyuan tech
-
Brand: HPE
Part Number: JL309A
Form Factor: QSFP28
Max. Data Rate: 100Gbps
Wavelength: 850nm
Max. Cable Distance: 100m
Connector: MTP/MPO-12/UPC
Media: MMF
Transmitter Type: II-VI VCSEL
Receiver Type: PIN
TX Power: -8.4~2.4dBm
Minimum Receiver Power: -10.3dBm
Power Budget: 1.9dB
Receiver Overload: 2.4dBm
Typical Power Consumption: ≤2.5W
Extinction Ratio: ＞2dB
DDM/DOM: Supported
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Modulation (Electrical): 4x 25G NRZ
Modulation (Optical): 4x 25G NRZ
CDR (Clock and Data Recovery): TX & RX Built-in CDR
Packaging Technology: COB (Chip on Board) Packaging
Bit Error Ratio (BER): 5E-5
MTBF: 30,800,000 Hours (@40°C, 60% CL)
Protocols: QSFP28 MSA, SFF-8636, IEEE 802.3bm, CAUI-4
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: MY
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
HPE JL309A 100GBASE-SR4 QSFP28 Optical Transceiver Module (MMF, 850nm, 100m, MTP/MPO, DOM)
The HPE JL309A QSFP28 Optical Transceiver Module is designed for use in 100GBASE Ethernet throughput up to 70m over OM3 and 100m over OM4 multimode fibre (MMF),
using a wavelength of 850nm via a MTP/MPO-12 connector. The module also supports breakout to 4x 25GBASE-SR SFP28. The transceiver is compliant with QSFP28 MSA, SFF-8636, IEEE 802.3bm,
and CAUI-4 standards. Digital diagnostics are provided via the I2C interface for real-time monitoring.
In addition to HPE JL309A , Liyuan Tech supply a wide range of other HPE series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
