HPE Aruba Series
HPE JG661A
- Product description: HPE JG661A _40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module_liyuan tech
-
Brand: HPE
Part Number: JG661A
Form Factor: QSFP+
Max. Data Rate: 40Gbps (4x 10Gbps)
Wavelength: 1310nm
Max. Transmission Distance: 10km
Connector: Duplex LC
Media: SMF
Transimitter Type: DFB CWDM
Receiver Type: PIN
TX Power: -7~2.3dBm
Receiver Sensitivity: <-11dBm
Power Budget: 4dB
Receiver Overload: 2.3dBm
Max. Power Consumption: ≤3.5W
Core Size: 9um
Extinction Ratio: >3.5dB
Modulation: NRZ
Host FEC: Supported
Bit Error Ratio (BER): 1E-12
Operating Temperature: 0 to 70°C (32 to 158°F)
Protocols: OTN OTU3, 40G Ethernet, Fiber Channel, SATA/SAS3, MSA Compliant
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Transportation method: Air freight
Warranty period: 180days
Country of origin: Thailand
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
HPE JG661A Compatible 40GBASE-LR4 QSFP+ Optical Transceiver Module (SMF, 1310nm, 10km, LC, DOM)
The HPE JG661A QSFP+ module is designed for use in 40GBASE Ethernet throughput up to 10km over single mode fibre (SMF) using a wavelength of 1310nm via duplex LC connectors.
This transceiver is compliant with QSFP+ MSA and IEEE 802.3ba 40GBASE-LR4 and OTU3 C4S1-2D1 standard. Digital diagnostics functions are also available via the I2C interface,
as specified by the QSFP+ MSA, to allow access to real-time operating parametres. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications,
such as data centres, high-performance computing networks, enterprise core and distribution layer applications.
In addition to HPE JG661A , Liyuan Tech supply a wide range of other HPEAruba series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
