HPE JD093B

Product description: HPE JD093B _10GBASE-LRM SFP+ 1310nm 220m DOM Duplex LC/UPC MMF/SMF Optical Transceiver_liyuan tech
INQUIRY

Brand: HPE
Part Number: JD093B
Form Factor: SFP+
Max. Data Rate: 10Gbps
Wavelength: 1310nm
Max. Transmission Distance: 220m
Connector: Duplex LC
Transmitter Type: FP 1310nm
Media: MMF/SMF
DOM Support: Yes
TX Power: -6.5~0.5dBm
Receiver Sensitivity: < -8.4dBm
Max. Power Consumption: ≤1W
Receiver Overload: +1.5dBm
Core Size: 50/125µm@OM3 MMF, 9/125μm@SMF
Modulation: NRZ
Operating Temperature: 0 to 70°C (32 to 158°F)
Protocols: IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI.
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Transportation method: Air freight
Warranty period: 180days
Country of origin: CHINA
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
HPE JD093B 10GBASE-LRM SFP+ Transceiver Module (MMF/SMF, 1310nm, 220m/300m, LC, DOM)
HPE JD093B SFP+ transceiver supports up to 220m over OM3 multimode fibre (MMF). This transceiver is compliant with SFF-8431,
SFF-8432 and IEEE 802.3aq 10GBASE-LRM. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472.
Featuring low power consumption, high speed, this 10G SFP+ transceiver is ideal for data centre, 10G Ethernet and Legacy FDDI multimode links etc.
In addition to HPE JD093B , Liyuan Tech supply a wide range of other HPEAruba series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
