HPE Aruba Series

HPE Aruba JD119B

Product description: HPE Aruba JD119B _1000BASE-LX SFP 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module_liyuan tech
INQUIRY

Brand: HPE
Part Number: Aruba JD119B
Form Factor：SFP
Max. Data Rate：1.25Gbps
Wavelength：1310nm
Max. Cable Distance：10km
Connector：Duplex LC
Media：SMF
Transmitter Type：FP
Receiver Type：PIN
DDM/DOM：Supported
Commercial Temperature Range：0 to 70°C (32 to 158°F)
TX Power：-9.5~-3dBm
Receiver Sensitivity：<-20dBm
Power Consumption：≤1W
Receiver Overload：-3dBm
Bit Error Ratio (BER)：1E-12
Extinction Ratio：>9dB
EMC (Electro Magnetic Compatibility)：Supported
MTBF (LX)：4,761,904 Hours
Protocols：IEEE 802.3ah-2004, IEEE 802.3z, SFF-8472, SFP MSA (INF-8074i) Compliant
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Inventory: There is inventory.
Warranty period: 180days
Country of origin: CHINA
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
HPE Aruba JD119B 1000BASE-LX SFP Transmission Module (SMF, 1310 nanometers, 550 meters/10 kilometers, LC, DOM)
The HPE Aruba JD119B SFP transceiver supports the longest 10-kilometer link length through LC duplex SMF optical fiber.
Each SFP transceiver module has been individually tested and can be used in a series of HPE switches, routers, servers, network interface cards (NICs), etc.
This transceiver has low power consumption and the hot-swappable 1G SFP transceiver is highly suitable for gigabit Ethernet communication links of Internet service providers (ISPs),
enterprise local area networks and storage area networks, data center local area networks and storage area networks, and other optical links.
In addition to HPE Aruba JD119B , Liyuan Tech supply a wide range of other HPEAruba series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
