HPE Aruba Series

HPE 845966-B21

Product description: HPE 845966-B21 _HPE 100Gb QSFP28 MPO SR4 100m Transceiver_liyuan tech
INQUIRY

Brand: HPE
Part Number: 845966-B21
Type: QSFP28
Transfer speed: 100Gb
Maximum distance: 100m
Wavelength: 850nm
Cable type: Optical fiber cable
Connector type: MPO
Fiber type: Multi-mode
Weight: 36.3 g (0.08 lb)
Dimensions: 18.35 x 72.7 x 8.5 mm
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Transportation method: Air freight
Warranty period: 180days
Country of origin: CHINA
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
The HPE 845966-B21 QSFP28 transceiver, 100G-QSFP28-100 model, is designed for dual-fiber multimode fiber (MMF) cables. It has a minimum guaranteed optical budget of 1.9 dB,
which is typically sufficient to cover approximately 100 meters of OM3 type fiber, and can reach up to 150 meters with higher category MMF fibers such as OM4 or OM5.
The calculation of distance takes into account the minimum (guaranteed) fiber budget and the average attenuation of optical cables in the industry.
The HPE 845966-B21 compatible transceiver uses high-quality VCSEL laser transmitters with a nominal wavelength of 850 nm and is equipped with 850 nm PIN photodiode receivers.
This module supports DDM/DOM optical diagnostics and provides diagnostic data on the current operating status.
The HPE 100Gb QSFP28 MPO SR4 100-meter transceiver is equipped with an MTP/MPO interface and is designed to operate in a standard temperature network environment of 0°-70°C.
This transceiver chipset supports data rates from 103.125 Gbps and applications such as 100G Ethernet (103.125 Gbps). It is a versatile transceiver that can be used in various different areas of today's networks.
Internet service provider (ISP) aggregation and backbone networks, core networks of mobile operators, and interconnections of data center core networks are the most popular applications for this product.
In addition to HPE 845966-B21 , Liyuan Tech supply a wide range of other HPE Aruba series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
