光学收发器
AVAGO ABCU-5710RZ
- 产品描述：AVAGO ABCU-5710RZ_10/100/1000Base-TX SFP Transceiver (Copper, 100m, RJ-45)_liyuan tech
-
Manufacturer: AVAGO
Part number: ABCU-5710RZ
Form Type: SFP
Transceiver Type: TX
Speed Description: 1.25-Gigabit
Wavelength: N/A
Media: Copper
Reach: 100m
DDM:DDM
Connector: RJ-45
DOM: DOM
Country of Origin: Malaysia
AVAGO ABCU-5710RZ is a gigabit electrical port (copper cable) optical transceiver module. Basic features:
Model: ABCU-5710RZ (SFP-1G-RJ-45-100M)
Type: Gigabit Ethernet electrical port SFP module (RJ-45 interface)
Rate: Supports 10/100/1000Mbps adaptive (compatible with Fast Ethernet and Gigabit Ethernet).
Transmission distance: Through standard Cat5/Cat6 network cables, the maximum distance is up to 100 meters (depending on cable quality).
Interface: RJ-45 connector (8P8C), supports automatic negotiation (Auto-Negotiation) and automatic crossover (Auto-MDIX).
2. Technical Specifications
Protocol Standards**:
IEEE 802.3 (10BASE-T)
IEEE 802.3u (100BASE-TX)
IEEE 802.3ab (1000BASE-T)
Power Supply Voltage: 3.3V (typical SFP power supply).
Power Consumption: Generally less than 1W, depending on the working mode.
Operating Temperature: Commercial grade (0°C to 70°C) or industrial grade (-40°C to 85°C, confirm the specific model suffix).
Compatibility: Supports MSA (Multi-Source Agreement) standard, compatible with most brand switches/routers (such as Cisco, HPE, Juniper, etc., confirm the compatibility list).
3. Functional Features
Adaptive Rate: Automatically matches 10M/100M/1000M network environments.
Plug-and-play: Hot-swappable design, no need to restart the device.
Low Latency: Suitable for scenarios requiring real-time performance (such as video surveillance, industrial networks).
Diagnostic Support: Some models support DDM (Digital Diagnostic Monitoring), which can monitor temperature, voltage, optical power, etc. (check if supported).
4. Application Scenarios
Enterprise network access layer (switch to terminal devices).
Data center short-distance copper cable connection.
Industrial Ethernet device interconnection.
Replace fixed electrical ports to enhance device port flexibility.
In addition to AVAGO ABCU-5710RZ , Liyuan Tech supply a wide range of other Optical transceiver . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
