ZTE series

  • ZTE GFBT GFGH GFTH GFXH GFBH GFBL GFBT GFCH EFTH
ZTE GFBT GFGH GFTH GFXH GFBH GFBL GFBT GFCH EFTH

ZTE GFBT GFGH GFTH GFXH GFBH GFBL GFBT GFCH EFTH

  • Product description: ZTE GFBT GFGH GFTH GFXH GFBH GFBL GFBT GFCH EFTH _ZTE ZXA10 C600 C650 C680 16-port GPON & XG-PON Combo OLT service card)_Liyuan tech
  • INQUIRY
Manufacturer: ZTE
Part number: GFBT GFGH GFTH GFXH GFBH GFBL GFBT GFCH EFTH
Port: 16-port
Interface: XG-PON & GPON Combo
Function: XG-PON & GPON service access
Specification: XG-PON & GPON Combo SFP+ interface, with built-in internal multiplexing, SC/UPC optical connector
Device Specifications
Weight: 1.72 kg
Dimensions (L x H x W): 393.1 mm × 23.9 mm × 214 mm
ZTE 16-port GPON & XG-PON Combo service card GFBT
Apply to ZTE ZXA10 C600/C650/C680 GPON OLT
Supports 16 XG-PON & GPON SFP+ hybrid interfaces
Maximum optical split ratio of GPON: 1:128
Maximum optical split ratio of XG-PON: 1:128
Support optical power monitoring
Support the ALS function of optical modules.
Support hot swapping
GFBT is a 16-port 10G GPON (XG-PON&GPON Combo) OLT subscriber card, which can be applied to ZTE ZXA10 C600/C650/C680 GPON OLT.
The combo PON solution multiplexes GPON and XG-PON optical wavelength channels in an optical module onto a single output optical port.
For XG-PON upgrade, the carrier only needs to replace the GPON line cards in OLTs with combo PON line cards and cut the optical fibers on the ,
original GPON line cards over to the combo PON line cards, so that the GPON and XG-PON can operate together.
Does GFBT support 16 XG-PON & GPON Combo SFP+ hybrid interfaces?
Yes, GFBT Supports 16 XG-PON & GPON SFP+ hybrid interfaces: maximum optical split ratio of GPON: 1:128; maximum optical split ratio of XG-PON: 1:128.
What is the difference between ZTE GFBT and GTGH interface card?
GFBT and GTGH are both ZTE 16-port interface card, but GFBT is XG-PON & GPON Combo card applied to ZTE ZXA10 C600/C650/C680 OLT; GTGH is 16-port GPON card applied to ZTE ZXA10 C320 C350 C300 OLT.
In addition to ZTE GFBT GFGH GFTH GFXH GFBH GFBL GFBT GFCH EFTH , Liyuan Tech has a wide range of other ZTE series . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
