SIEMENS 6FC5370-0AA00-3AA1 6FC5370-0AA00-2AA1 6FC5500-0AA11-1AA0 6FC5370-1AM00-0CA0

Product description: SIEMENS 6FC5370-0AA00-3AA1 6FC5370-0AA00-2AA1 6FC5500-0AA11-1AA0 6FC5370-1AM00-0CA0_SINUMERIK 802D sl version T/M pro CNC operator panel with_liyuan tech
INQUIRY

Manufacturer: SIEMENS
Part Number: 6FC5370-0AA00-3AA1 6FC5370-0AA00-2AA1 6FC5500-0AA11-1AA0 6FC5370-1AM00-0CA0
product description: SINUMERIK 802D sl version T/M pro CNC operator panel with NC, PLC, HMI part and drive control for SINAMICS axes/spindles (4/1 or 3/2) including logbook and tool box.
Net Weight (kg): 5.6 Kg
Shipping weight : 8.5 Kg
Availability: Used
Lead time-7days
Trading terms: TT
Warranty period: 180days
Country of origin: CHINA
1. Product classification and application
Series: SINUMERIK 840D/840D sl (System modules or driver-related components).
Function: This module may be a drive control module or an interface module, responsible for coordinating communication and signal processing between the,
numerical control system and the servo driver and motor, ensuring the high precision and dynamic response of the machine tool's movement.
2. Key Features
High-precision control: Supports multi-axis linkage and is suitable for complex processing tasks (such as five-axis processing).
Real-time communication: Connect to the upper-level system and driver unit via PROFIBUS or PROFINET to ensure low-latency data transmission.
Modular design: Strong scalability, compatible with various Siemens drivers and motors (such as 1FK/1PH series servo motors).
Industrial-grade reliability: Adaptable to harsh industrial environments (high temperatures, vibrations, electromagnetic interference).
3. Technical Parameters (Typical Values)
Power input: It is usually 24V DC or three-phase AC power (for specific details, please refer to the manual).
Communication interfaces: PROFIBUS DP, PROFINET (depending on the firmware version).
Compatibility: Works in coordination with systems such as SINUMERIK 840D sl and SIMODRIVE 611D.
Operating temperature: 0°C to 55°C (industrial standard).
4. Application Scenarios
CNC machine tools: milling machines, lathes, machining centers.
Automated production line: Integrated into the Flexible Manufacturing System (FMS), supporting unmanned production.
High-precision processing: aerospace, automotive mold, medical device manufacturing.
5. Model Analysis
6FC: Product series identification of Siemens numerical control systems.
5370: Sub-series or module type (possibly representing the drive control unit).
Version/configuration code, which may indicate differences in voltage level, communication protocol or firmware version.
6. Precautions
Compatibility: It needs to be matched with the same series of numerical control systems (such as NCU, PCU units) and drivers.
Technical Support: It is recommended to obtain detailed manuals through the official channels of Siemens (such as "SINUMERIK 840D sl Commissioning Guide").
