SIEMENS Series

SIEMENS 6ES7518-4UP00-0AB0 6ES7517-3HP00-0AB0 6ES7517-3FP00-0AB0 6ES7518-4AP00-3AB0 6ES7517-3AP00-0AB0 6ES7517-3UP00-0AB0 6ES7500-0HP00-0AB0

Product description: SIEMENS 6ES7518-4UP00-0AB0 6ES7517-3HP00-0AB0 6ES7517-3FP00-0AB0 6ES7518-4AP00-3AB0 6ES7517-3AP00-0AB0 6ES7517-3UP00-0AB0 6ES7500-0HP00-0AB0_SIMATIC S7-1500TF, CPU 1518TF-4 PN/DP_Liyuan tech
INQUIRY

Manufacturer: SIEMENS
Part Number: 6ES7518-4UP00-0AB0 6ES7517-3HP00-0AB0 6ES7517-3FP00-0AB0 6ES7518-4AP00-3AB0 6ES7517-3AP00-0AB0 6ES7517-3UP00-0AB0 6ES7500-0HP00-0AB0
Product family: CPU 1518TF-4 PN/DP
Product Lifecycle (PLM): PM300:Active Product
Weight : 2.26 Kg
Packaging Dimension: 15,10 x 15,40 x 4,60
Shipping weight : 5 Kg
Availability: Used
Lead time-7days
Trading terms: TT
Warranty period: 180days
Country of origin: Germany
describe: SIMATIC S7-1500TF, CPU 1518TF-4 PN/DP, central processing unit with 9 MB work memory for program and 60 MB for data, 1st interface: PROFINET IRT with 2-port switch,
2nd interface: PROFINET RT, 3rd interface: PROFINET basic services, 4th interface: PROFIBUS, 1 ns bit performance, SIMATIC memory card required
Siemens 6ES7518-4UP00-0AB0 is a high-performance programmable logic controller (PLC) CPU module in the SIMATIC S7-1500 series.
The specific model is CPU 1518-4 PN/DP. The following is its detailed introduction and typical application scenarios:
Key features of the product
High-performance processing capability
Equipped with a multi-core processor, it supports extremely fast instruction execution speed (for example, bit operation only requires 1ns), and is suitable for complex algorithms and large-scale data processing.
Large-capacity working memory (such as 4MB) and integrated loading memory, supporting large programs and data logging.
2. Communication interface
2x PROFINET interface: Supports Gigabit Ethernet and is used for real-time communication (RT/IRT), OPC UA, TCP/IP and other protocols.
1x PROFIBUS DP Interface: Compatible with traditional Profibus devices to achieve field-level communication.
Support the expansion of more communication protocols (such as Modbus TCP, EtherNet/IP) through the CM/CP module.
3. Expansion capability
It supports up to 32 module expansions (including digital/analog I/O, communication, functional modules, etc.).
Supports distributed I/O (such as ET 200SP/MP), and is suitable for distributed control systems.
4. Function Integration
Motion control: Supports multi-axis synchronous control (such as CNC, robot control).
Safety function: It can be expanded to a **Fail-Safe CPU** (with F-series modules required) to achieve SIL3 safety level.
Web server: Remotely monitor the status of devices and diagnose faults through web pages.
5. Real-time performance and redundancy
Supports Precise Time Protocol (PTP) to meet the requirements of high-precision synchronization (such as motion control).
Optional redundant configuration is available to enhance system availability (such as in the energy and chemical industries).
Typical usage scenarios
1. Complex automated systems
Automobile manufacturing: High-precision control of body welding and painting production lines.
Packaging machinery: High-speed synchronous control (such as integrated equipment for filling, labeling and boxing).
2. Process industry
Chemical Engineering/Pharmaceutical: Central control system, integrating PID control, batch management, and safety interlock.
Water treatment: Data Acquisition and Monitoring (SCADA) for pumping stations and filtration systems.
3. Logistics and Energy
Warehouse automation: Multi-axis motion control of stacker cranes and sorting systems.
Energy management: Grid monitoring, real-time data processing of renewable energy (wind power/photovoltaic).
4. High availability scenarios
Oil and gas: Redundant configuration ensures continuous production and avoids the risk of downtime.
Data center: Intelligent monitoring of infrastructure (cooling, power supply).
In addition to SIEMENS 6ES7518-4UP00-0AB0 6ES7517-3HP00-0AB0 6ES7517-3FP00-0AB0 6ES7518-4AP00-3AB0 6ES7517-3AP00-0AB0 6ES7517-3UP00-0AB0 6ES7500-0HP00-0AB0，Liyuan Tech supply a wide range of other SIEMENS Series .If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
