Optical transceiver
Mellanox MMA1T00-VS
- Product description: Mellanox MMA1T00-VS_200GBase-SR4 QSFP56 Transceiver (MMF, 850nm, 100m, MPO, DOM)_liyuan tech
-
Manufacturer: Mellanox
Part number: MMA1T00-VS
Form Type: QSFP56
Speed : 200FB
Reach: 100m
Wavelength: 850nm
Media: MMF
Transceiver Type: SR4
Connector: MPO
DOM: DOM
Availability: Used
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: Thailand
Environment：0 to 70°C
The Mellanox MMA1T00 adapter is a 4-channel, plug-in QSFP56 optical transceiver specifically designed for 200GbE Ethernet applications.
This module utilizes Mellanox 's integrated circuit technology to achieve high performance. The transceiver operates through 4 parallel multimode fibers (MMF),
with a nominal wavelength of 850 nanometers and in accordance with the QSFP56 MSA standard.
The transceiver has a QSFP56 connector compliant with the SFF-8665 standard at the electrical end face of the host system. Its optical interface consists of four optical channels/fibers in each direction,
aimed at achieving parallel multimode optical cable connections through the standard MPO-12 UPC connector. The maximum working signal rate of each channel/fiber can reach up to 26.5625 GBd.
Strict production tests ensure the best factory installation experience, performance, and durability.
The MMA1T00 communicator has a digital diagnostic monitoring function, which can monitor power voltage, temperature, laser bias current,
optical transmission and reception levels, and has corresponding warning and alarm thresholds.
The MMA1T00 radio transceiver will be used in conjunction with fiber equipment according to the scheme specified in the QSFP MSA standard.
In addition to Mellanox MMA1T00-VS , Liyuan Tech supply a wide range of other Optical transceiver . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
