Optical transceiver
INTEL AFBR-709DMZ-IN3
- Product description: INTEL AFBR-709DMZ-IN3_1G/10G 850nm Multimode SFP+ Transceiver _liyuan tech
-
Manufacturer: INTEL
Part number: AFBR-709DMZ-IN3
Form Type：SFP
Speed: 10GB
Reach: 300m
Wavelength: 850nm
DOM：DOM
Media：SMF
Key Features:
Hot-pluggable Sfp+ Footprint
Supports Rate Selectable 1.25 Gb/s Or 9.95 To 10.3 Gb/s Bit Rates
Power Dissipation < 1w
Rohs-6 Compliant (lead-free)
Single 3.3v Power Supply
Maximum Link Length Of 400m On Om4 Mmf
Uncooled 850nm Vcsel Laser
Receiver Limiting Electrical Interface
Duplex Lc Connector
Built-in Digital Diagnostic Functions
Receiver Type: PIN photodiode
Power: +3.3V single power supply
Availability: Used
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: Thailand
Environment：0 to 70°C
INTEL AFBR-709DMZ-IN3 1g/10g Dual Rate (10gbase-sr And 1000base-sx) 400m Multimode Datacom Sfp+ Optical Transceiver.
Intel AFBR-709DMZ-IN3 SFP+ transceiver 10G-SFP-300-meter product. This product has the same parameters and is manufactured according to the same industry standards.
This module version is designed for dual-fiber multimode fiber (MMF) optical cables. Its minimum guaranteed fiber budget is 4.6 dB,
which is usually sufficient to cover approximately 300 meters of OM3 type fiber or 400 meters of OM4 or higher MMF type fiber. However, distance is only an indicative parameter for comfort.
Finally, when we calculate the distance, we take into account the minimum (guaranteed) fiber budget and the average attenuation of optical cables in the industry.
The Intel AFBR-709DMZ-IN3 transceiver uses a high-quality VSCEL laser transmitter,
with a working frequency of 850 nanometers and an 850 nanometer PIN photodiode receiver. This module supports DDM/DOM optical diagnostics and provides diagnostic data on the current working state.
This compatible module is equipped with dual LC connectors, designed for a standard temperature network environment of 0° - 70°C.
This transceiver chipset supports data rates of 1.25 - 10.31 Gbps, supporting 10G Ethernet (10.31 Gbps), Gigabit Ethernet (1.25 Gbps),
STM-64 (9.95 Gbps), etc. for applications. Ensure the original factory quality of the module. This is a multi-purpose transceiver that can be used in various different fields of today's networks.
Applications such as Internet Service Provider (ISP) fiber-to-the-home aggregation and backbone networks, mobile operator core networks,
and mobile backhaul and data center network site interconnections are the most popular applications for this product.
In addition to INTEL AFBR-709DMZ-IN3 , Liyuan Tech supply a wide range of other Optical transceiver . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
