Mellanox MMA1B00-C100D
- Product description: Mellanox MMA1B00-C100D _100GbE QSFP28/850nm SR4/Up to 100m_liyuan tech
-
Brand: Mellanox
Part Number: MMA1B00-C100D
Type: Transceiver
Interface: QSFP28
Data Rate: 100GbE
Wavelength: 850nm
Maximum Distance: 100m
Connector: MPO
Cable Type: Multimode Fiber
DDMI: Yes
Operating Temperature: 0°C to 70°C
Power Consumption :3.5W (Max)
Form Factor: QSFP28
Application: Data Center, High-Performance Computing
Forward Error Correction (FEC): Supported
Compliance: RoHS-6 Compliant
Dimensions: 4.74" x 0.71" x 0.33" (120.4mm x 18.1mm x 8.5mm)
Reliability: MTBF > 1 million hours
Regulatory Approvals: CE, FCC, FDA
Compatibility: Compatible with a wide range of switches and routers
Product Features
Supports 100 Gigabit Ethernet (100GbE) connectivity.
Utilizes the QSFP28 form factor for high port density.
Operates over multimode fiber with a wavelength of 850nm.
Offers a maximum reach of 100 meters with MPO connectors.
Includes Digital Diagnostic Monitoring Interface (DDMI) for real-time performance monitoring.
Product Applications
Ideal for high-speed data center interconnects.
Suitable for high-performance computing (HPC) environments requiring low-latency connectivity.
Perfect for enterprise network backbones that demand high bandwidth and reliability.
MPO to MPO Cable: CAB-MPO-MPO-3M
QSFP28 Adapter: ADP-QSFP28-SFP28
Cleaning Tool: CLN-MPO-TOOL
Mellanox MMA1B00-C100U: Operates at 1310nm wavelength, supports single-mode fiber.
Arista QSFP-100G-SR4: Similar specifications but from a different brand.
Cisco QSFP-100G-SR4-S: Provides enhanced reach up to 150 meters on OM4 multimode fiber.
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: Thailand
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
Mellanox MMA1B00-C100D Overview
The Mellanox MMA1B00-C100D is a high-performance 100GbE transceiver designed to meet the growing needs of data centers and enterprise networks.
This QSFP28 SR4 transceiver operates at a wavelength of 850nm and provides reliable connectivity up to distances of 100 meters using MPO connectors.
It features Digital Diagnostic Monitoring Interface (DDMI) for enhanced management and diagnostics, making it an ideal solution for high-speed data transmission.
In addition to Mellanox MMA1B00-C100D , Liyuan Tech supply a wide range of other Mellanox series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
