Finisar Series

FINISAR FTCF2519E6PCA FTCF2519E6PCM

Product description: FINISAR FTCF2519E6PCA FTCF2519E6PCM _1.6T-DR8 (2xDR4) OSFP Finisar Transceiver_liyuan tech
INQUIRY

Manufacturer: FINISAR
Part number: FTCF2519E6PCA FTCF2519E6PCM
Product Category: Optical Transceiver
Form Type: OSFP
Speed Description: 1.6T
Reach: 500m
Wavelength: 1310nm
MPO-12: MPO-12
Media: SMF
Transceiver Type: DR8
Hot-pluggable OSFP form factor type 2
1.6Tbps aggregate bit rate
Power dissipation < 26W
Case temp range of 0°C to +70°C
500m max on single mode fiber
Single 3.3V power supply
8x200G PAM4 optical interface
8x200G PAM4 electrical interface
Single MPO16 or Dual MPO12
receptacle options
Riding Heatsink (RHS) and
APPLICATIONS
Integrated Heatsink (IHS) options
1.6Tbps AI/ML applications and
I2C management interface
The FTCF2519E6PCA OSFP transceiver modules are designed for use in 1.6Tbps Ethernet links on up to 500m of single mode fiber. They are compliant with the OSFP MSA
and portions of IEEE P802.3dj and 8x200G PAM4 per OIF 224G-VSR
Digital diagnostic functions are available via the I2C interface, as specified by the OSFP MSA. The transceiver is RoHS-6
compliant per Directive 2011/65/EU4 and Finisar Application Note AN-2038
Lead time-7days
Trading terms: TT wire transfer
Transportation method: Air freight
Warranty period: 180days
Country of origin: MY
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
In addition to FINISAR FTCF2519E6PCA FTCF2519E6PCM , Liyuan Tech supply a wide range of other FINISAR Series . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
