Nokia 3HE05037AA
- 产品描述：Nokia 3HE05037AA _10GBase-BX SFP+ Transceiver (SMF, 1270nmTx/1330nmRx, 20km, LC, DOM)_liyuan tech
-
Manufacturer: Nokia
Part Number: 3HE05037AA
CLEI: IPUIBHHDAA
Form Type: SFP+
Speed Description: 10-Gigabit
Reach: 20km
Wavelength: 1270nmTx/1330nmRx
Transceiver Type: BX
Media: SMF
Connector: LC
DOM: DOM
Product Description
Model: Nokia 3HE05037AA
This is a product of the Nokia brand (formerly under Alcatel-Lucent), typically used in Nokia/Alcatel-Lucent switches, routers,
and transmission equipment (such as 7x50 series, SR series, etc.), but also compatible with SFP+ ports of other major network equipment vendors (compatibility needs to be confirmed).
Rate and Standard: 10GBase-BX
10GBase: Compliant with IEEE 802.3ae standard, supporting a data transmission rate of 10Gbps (10 Gigabit).
BX: An abbreviation for "Bi-Directional Single Fiber", which is the core feature of this module. It allows simultaneous data transmission (Tx) and reception (Rx) over a single-mode fiber, thus saving half of the fiber resources.
Fiber Type and Distance: SMF, 20km
SMF: Single-mode fiber. Suitable for long-distance, high-speed data transmission.
20km: The maximum transmission distance can reach 20 kilometers. This makes it an ideal choice for metropolitan area networks (MAN), remote access, and inter-park connections.
Wavelength: 1270nm Tx / 1330nm Rx
Tx: 1270nm - This is the optical wavelength used by the module when sending data.
Rx: 1330nm - This is the wavelength the module listens to when receiving data from the opposite end device.
This asymmetric wavelength design is key to achieving single-fiber bidirectional communication.
It must be used with a matching module with opposite wavelengths (1330nm Tx / 1270nm Rx) to function properly.
Interface: LC
Uses the standard LC type optical fiber connector, which is the most common interface type for SFP/SFP+ modules.
Features: DOM
Digital Optical Monitoring. Modules supporting this feature can report working parameters in real-time to network management systems (such as NMS), including:
Tx Power (Transmit Power), Rx Power (Receive Power), Supply Voltage
Laser Bias Current, Temperature
The DOM function is crucial for network diagnosis, preventive maintenance, and troubleshooting.
Summary of Core Features: This is a single-fiber bidirectional 10G SFP+ optical module that can achieve 10Gbps data transmission over 20 kilometers using a single-mode fiber and supports digital monitoring.
Application Scenarios
The design features of this module determine that it is mainly applied in scenarios where fiber resources need to be saved and medium to long-distance point-to-point connections are required.
1. MAN Access with Scarce Fiber Resources
In cities, both fiber ducts and fibers themselves are precious resources. Using BX series single-fiber bidirectional modules can reduce fiber consumption by half,
significantly lowering cabling costs and complexity. It is highly suitable for aggregating multiple remote sites (such as base stations, branch offices) to a central data center.
2. Interconnection of Enterprise Campuses and Data Centers (DCI)
Connecting enterprise campus buildings or data centers located in different geographical locations. If the number of fiber cores laid between the two locations is limited,
this module can quickly establish a 10Gbps interconnection link without adding new fibers.
3. Telecommunication Operator Networks (FTTx Backhaul)
In fiber-to-the-home (FTTH) networks, it can be used to connect OLT (Optical Line Terminal) and remote splitter nodes or aggregation switches as an uplink backhaul link, fully utilizing existing fiber infrastructure.
4. Point-to-point dedicated lines
We offer dedicated line services up to 20 kilometers for customers who require high-speed, stable, and dedicated links, such as financial institutions, government agencies, and large enterprises.
In addition to Nokia 3HE05037AA , Liyuan Tech supply a wide range of other Nokia Series . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
