Nokia 1AB377220003 1AB377220004 1AB377220006 1AB377220007 1AB377220008 1AB377220009 1AB377220010 1AB377220011 1AB377220012 1AB377220013 1AB377220014 1AB377220015 1AB377220016

产品描述：Nokia 1AB377220003 1AB377220004 1AB377220006 1AB377220007 1AB377220008 1AB377220009 1AB377220010 1AB377220011 1AB377220012 1AB377220013 1AB377220014 1AB377220015 1AB377220016
在线订购

Manufacturer: Nokia
Part number: 1AB377220003 1AB377220004 1AB377220006 1AB377220007 1AB377220008 1AB377220009 1AB377220010 1AB377220011 1AB377220012 1AB377220013 1AB377220014 1AB377220015 1AB377220016
Form Type: SFP
Transceiver Type: DWDM
Speed Description: 2-Gigabit
Wavelength: 1529.55nm
Media: SMF
Reach: 80km
Connector: LC
DOM: DOM
Part number:
1AB377220003 SFP DWDM CH 60
1AB377220004 SFP DWDM CH 59
1AB377220005 SFP DWDM CH 58
1AB377220006 SFP DWDM CH 57
1AB377220007 SFP DWDM CH 56
1AB377220008 SFP DWDM CH 55
1AB377220009 SFP DWDM CH 54
1AB377220010 SFP DWDM CH 53
1AB377220011 SFP DWDM CH 52
1AB377220012 SFP DWDM CH 51
1AB377220013 SFP DWDM CH 50
1AB377220014 SFP DWDM CH 49
1AB377220015 SFP DWDM CH 48
1AB377220016 SFP DWDM CH 47
1AB377220017 SFP DWDM CH 46
1AB377220018 SFP DWDM CH 45
1AB377220019 SFP DWDM CH 44
1AB377220020 SFP DWDM CH 43
1AB377220021 SFP DWDM CH 42
1AB377220022 SFP DWDM CH 41
1AB377220023 SFP DWDM CH 40
1AB377220024 SFP DWDM CH 39
1AB377220025 SFP DWDM CH 38
1AB377220026 SFP DWDM CH 37
1AB377220027 SFP DWDM CH 36
1AB377220028 SFP DWDM CH 35
1AB377220029 SFP DWDM CH 34
1AB377220030 SFP DWDM CH 33
1AB377220031 SFP DWDM CH 32
1AB377220032 SFP DWDM CH 31
1AB377220033 SFP DWDM CH 30
1AB377220034 SFP DWDM CH 29
1AB377220035 SFP DWDM CH 28
1AB377220036 SFP DWDM CH 27
1AB377220037 SFP DWDM CH 26
1AB377220038 SFP DWDM CH 25
1AB377220039 SFP DWDM CH 24
1AB377220040 SFP DWDM CH 23
1AB377220041 SFP DWDM CH 22
1AB377220042 SFP DWDM CH 21
1AB377220043 SFP DWDM CH 20
1AB377220044 SFP DWDM CH 19
1AB377220045 SFP DWDM CH 18
1AB377220046 SFP DWDM CH 17

Nokia 1AB377220003 Product Overview:

Model: 1AB377220003
Type: SFP (Small Form-factor Pluggable) optical module, supporting hot-swapping.
Rate: 2.5 Gbps (compatible with 2.488 Gbps, such as OC-48/STM-16 or Gigabit Ethernet).
Transmission Distance: 80 kilometers (long-distance transmission, requires the use of single-mode fiber (SMF)).
Wavelength: 1529.55 nm, belonging to DWDM (Dense Wavelength Division Multiplexing) channel, in line with ITU-T wavelength standards.
Applications: Suitable for high-density, large-capacity DWDM optical networks, such as metropolitan area networks (MAN), backbone networks, or long-distance telecommunications transmission.
Key Features
1. DWDM Technology
Supports specific wavelengths specified by ITU-T (1529.55 nm), can be multiplexed with other DWDM channels, enhancing the utilization of fiber bandwidth.
Channel spacing is typically 100 GHz or 50 GHz (please confirm the specific specifications).
2. Long-Distance Transmission
80 km transmission distance, requires the use of single-mode fiber (SMF) and possibly a dispersion compensation module (DCM).
May include an APD (Avalanche Photodiode) receiver or high-performance laser to support long-distance.
3. Compatibility
Complies with SFP MSA (Multi-Source Agreement) standards, compatible with Nokia and third-party devices supporting SFP interfaces.
Supports digital diagnostic monitoring (DDM/DOM), allowing monitoring of parameters such as optical power and temperature through the network management system.
4. Environmental Adaptability
Operating temperature range: commercial grade (0°C to +70°C) or industrial grade (-40°C to +85°C), please confirm according to the model suffix.
Typical Application Scenarios
Telecom Operator Networks: Used for 2.5G service transmission in DWDM systems (such as SDH/SONET, Ethernet).
Enterprise Private Lines: Long-distance point-to-point or ring network connections.
Data Center Interconnection (DCI): High-density wavelength multiplexing scenarios.
In addition to Nokia 1AB377220003 1AB377220004 1AB377220006 1AB377220007 1AB377220008 1AB377220009 1AB377220010 1AB377220011 1AB377220012 1AB377220013 1AB377220014 1AB377220015 1AB377220016 ,
Liyuan Tech supply a wide range of other Nokia Series . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
