FINISAR FTCC1112E1PLLFB6 FTCC1112E1PLLFB8
- 产品描述：FINISAR FTCC1112E1PLLFB6 FTCC1112E1PLLFB8 _QSFP28 200G-FR4 1310nm CWDM 3KM SMF_liyuan tech
-
Brand: FINISAR
Part Number: FTCC1112E1PLLFB6 FTCC1112E1PLLFB8
Form Type: QSFP28
Speed: 200GBase
Reach: 3KM
Wavelength: 1310nm
Interface Type: FR4
Application: Ethernet
Media: SMF
CWDM:CWDM
Connector: Dual LC
DOM: DOM
DDM: DDM
Country of Origin: Malaysia
Finisar FTCC1112E1PLLFB6（QSFP28-200G-FR4）
1. Product Overview
Model: FTCC1112E1PLLFB6
Package Type: QSFP28 (Quad Small Form-factor Pluggable 28)
Rate: 200Gbps (4×50G PAM4)
Standard: Compliant with IEEE 802.3bs 200GBASE-FR4 and QSFP28 MSA specifications
Application: Data centers, high-speed network interconnection, enterprise core networks.
2. Key Parameters
Wavelength: 1310nm CWDM (4 channels, wavelength range approximately 1271~1331nm)
Transmission Distance: 3 kilometers (Single-mode Fiber, SMF)
Modulation Format: PAM4 (4-level Pulse Amplitude Modulation)
Data Rate: 50Gbps per channel, total bandwidth 200Gbps
Connector: Duplex LC interface
3. Physical Layer Characteristics
Fiber Type: Single-mode Fiber (SMF, ITU-T G.652)
Maximum Power Consumption: ≤8W (typical value)
Operating Temperature: 0°C to +70°C (commercial grade)
Digital Diagnostics: Supports DDM (Digital Diagnostic Monitoring), real-time monitoring of temperature, voltage, optical power, etc.
4. Protocol and Compatibility
Supported Protocols:
200GBASE-FR4 (IEEE 802.3bs)
Compatible with 100G Ethernet (via rate negotiation)
Forward Error Correction (FEC): Supports IEEE standard FEC to ensure low bit error rate.
5. Typical Application Scenarios
Data Center Interconnection (DCI)
Metropolitan Area Network (MAN) short-distance transmission
High-performance computing (HPC) and cloud storage networks
6. Certification and Reliability
Certification: Compliant with RoHS, CE, FCC, etc.
MTBF: High-reliability design, average mean time between failures > 1 million hours
7. Advantages
High Density: QSFP28 packaging saves space, suitable for high-density deployment.
Low Power Consumption: Optimized energy efficiency, suitable for large-scale data centers.
Plug and Play: Hot-swappable design, supports rapid deployment.
