  • Cisco CFP2-WDM-DS-1HL
Cisco CFP2-WDM-DS-1HL

Cisco CFP2-WDM-DS-1HL

  • 产品描述:Cisco CFP2-WDM-DS-1HL_200G, 100G, WDM digital CFP2 pluggable only licensed 100G - non-TOF version _Liyuan Tech
  • 在线订购

Brand: Cisco

Model: CFP2-WDM-DS-1HL

Encapsulation mode: CFP2

Description: 200G, 100G, WDM digital CFP2 pluggable only licensed 100G - non-TOF version

Product Category: Pluggable optical module

Data rate: 200 gigabytes

Distance: 80 km

Optical fiber type: SMF

Wavelength: 1528.77 nm-1568.36 nm

Connector: LC

WDM: WDM

Application: 200G Ethernet

Operating temperature: 0 ℃ to 70 ℃

Cisco offers different versions of digital CFP2. Table 1 lists the Pids of products containing so-called "tunable optical filters (TOF)". The Pids listed in Table 2 are exactly the same as the previous module in Table 1, except that this version does not have TOF. The presence of TOF in a module is associated with the application that will be used. TOF allows pluggable DWDM systems for long range amplification. Removing the TOF module from the pluggable module can reduce costs, while applications should be limited to dark fiber systems. Although the customer network may or may not need to support DWDM


In addition to CFP2-WDM-DS-1HL , Liyuan Tech supply a wide range of other Cisco transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
