Optical transceiver

SOURCE SPQ-4E-FR-CDFC

Product description: SOURCE SPQ-4E-FR-CDFC _400GBASE-FR4 QSFP-DD 1310NM 2KM EML_liyuan tech
INQUIRY

Brand: SOURCE
Part Number: SPQ-4E-FR-CDFC
Form Factor: QSFP-DD
Data Rate: 400Gb/s
Wavelength: 1310NM
Reach: 2KM
Transmitter: EML
Receiver: PIN
Wavelength (nm): CWDM
Compliant with 400G-FR4 (IEEE892.3cu)
Compliant with IEEE 802.3bs standard: 400GAUI-8 electrical interface
Compliant with QSFP-DD MSA HW Rev 5.1;
type 2 housing with duplex LC connector
Compliant with QSFP-DD CMIS Rev 4.0
Maximum power consumption 10 W
Case operating temperature 0°C to 70°C
Two wire serial Interface with digital diagnostic monitoring
Complies with EU Directive 2011/65/EU (RoHS compliant)
Class 1 Laser
Availability: NEW
Lead time-7days
Inventory: 300 units
Trading terms: TT wire transfer
Transportation method: Air freight
Warranty period: 180days
Country of origin: CHINA
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
describe：400GBASE-FR4 QSFP-DD 1310NM 2KM EML
In addition to SOURCE SPQ-4E-FR-CDFC , Liyuan Tech supply a wide range of other Optical transceiver . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
