NVIDIA MMA4Z00-NS
- Product description: NVIDIA MMA4Z00-NS _800G 2xSR4/SR8 OSFP PAM4 850nm 50m DOM Two MPO-12/APC InfiniBand NDR Transceiver Module for MMF (Finned Top)_liyuan tech
-
Manufacturer: NVIDIA
Part number: MMA4Z00-NS
Form Factor: OSFP
Speed Description: 800GB
Distance: 50m
Wavelength: 850nm
Connector: Two MPO-12/APC
Power Consumption: ≤14W
Transmitter: VCSEL
Receiver: PIN
Media: MMF
Modulation (electrical): 8x106.25Gb/s PAM4
Modulation (Optical): Two ports 4x106.25Gb/s PAM4
Case Temperature (℃): 0~70°C (32 to 158°F)
Protocol: IB NDR, 800G Ethernet Compliant
Vailability: NEW
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: MY
Operating Temperature: 0 to 70°C
NVIDIA MMA4Z00-NS is combined with Broadcom DSP and Broadcom VCSEL 800G 2xSR4/SR8 InfiniBand NDR optical transceiver module (dual-port OSFP, 850nm, 30m (OM3)/50m (OM4), two MPO-12/APC, DOM,
suitable for MMF, with heat sink fins on top). The NADDOD OSFP-800G-2xSR4H is manufactured using Broadcom DSP and Broadcom VCSEL technology.
It is an 800Gb/s dual-channel 400Gb/s dual-mode SR8 parallel 8-channel transceiver based on InfiniBand and Ethernet, using two 4-channel MPO-12/APC optical connectors.
Each port has a transmission rate of 400Gb/s. The dual-channel SR8 transceiver is a key innovation,
with its internal structure containing two transceiver engines, enabling 64 400Gb/s ports in 32 OSFP racks of the Quantum-2 switch. The Spectrum-4 switch has 32 or 64 racks and can provide 64 - 128 400G ports.
In addition to NVIDIA MMA4Z00-NS , Liyuan Tech supply a wide range of other NVIDIA GPU Graphics card family . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
