NVIDIA 920-9B210-00FN-0D0
- Product description: NVIDIA 920-9B210-00FN-0D0 _64-port NDR, 32 OSFP ports, non-managed P2c airflow (forward)_liyuan tech
-
Manufacturer: NVIDIA
Part number: 920-9B210-00FN-0D0
Product Overview
NVIDIA 920-9B210-00FN-0D0 64-ports Ndr 32 Osfp Ports Unmanaged P2c Airflow (forward)
System Specifications
Performance 400gb/s Per Port
Switch Radix 64 Ndr Non-blocking Ports With Aggregate Data Throughput Up To 51.2tb/s
Connectors And Cabling 32 Octal Small Form-factor Pluggable (osfp) Connectors, Passive Or Active Copper Or Active Fiber Cable, Optical Module
System Power Usage
Maximum Power With Passive Cables: 1,084w
Maximum Power With Optical Cables (with Each Port Consuming 18.5w): 1,720w
Power Supply 1+1 Redundant And Hot-swappable Power Input Range: 200-240vac 80 Gold+ And Energy Star Certified
Cooling Unmanaged P2c Airflow (forward).
Management Ports
1x Usb 3.0 X1
1x Usb For I2c Channel
1x Rj45
1x Rj45 (uart)
Cpu X86 Coffee Lake I3
System Memory Single 8gb, 2,666 Mega Transfers Per Second (mt/s), Ddr4 So-dimm
Storage M.2 Ssd Sata 16gb 2242 Ff
Software Mlnx-os
System Dimensions
Height: 1.7in (43.6mm)
Width: 17.0in (438mm)
Depth: 26.0in (660.4mm)
System Weight 14.5kg
Rack Mount 1u Rack Mount
Operating Conditions
Temperature:
> Operating 0 (degree C) To 40(degree C)
> Non-operating -40(degree C) To 70(degree C)
Humidity:
> Operating 10% To 85% Non-condensin
> Non-operating 10% To 90% Non-condensing
Altitude: Up To 3050m
Product Safety Compliant/certified Rohs, Cb, Ctuvus,ce, And Cu
Vailability: Used
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: TAIWAN
Operating Temperature: 0 to 70°C
In addition to NVIDIA 920-9B210-00FN-0D0 , Liyuan Tech supply a wide range of other NVIDIA GPU Graphics card family . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
