Mellanox MMS1W50-HM

Product description: Mellanox MMS1W50-HM _QSFP56 200G FR4 PAM4 1310nm 2km DOM Duplex LC/UPC SMF Optical Transceiver Module_Liyuan tech
INQUIRY

Manufacturer: Mellanox
Part Number: MMS1W50-HM
Form Factor: QSFP56
Max Data Rate: 200Gbps
Max Cable Distance: 2km
Cable Type: SMF
Wavelength: 1310nm
Max Cable Distance: 2km
Cable Type: SMF
Connector: Duplex LC/UPC
Modulation: PAM4
TX Power: -4.2 to 4.7 dBm
Interface Type: FR4
Receiver Sensitivity: <-8.2dBm
Transmitter Type: DML
Power Consumption: ≤5.5W
Application: InfiniBand HDR, 200G Ethernet
DDM/DOM: Supported
Receiver Type: PIN
Availability: Used
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: China
Temperature Range: 0 to 70°C (32 to 158°F)
Mellanox MMS1W50-HM InfiniBand HDR QSFP56 200G FR4 PAM4 Optical Transceiver Module (SMF, 1310nm, 2 km, duplex LC connector, DOM)
The 200G QSFP56 FR4 InfiniBand HDR optical module supports a maximum speed of 200 Gb/s, with a short distance of up to 2 km, and is connected through OS2 single-mode fiber (SMF).
The QSFP56-200G-FR4 is based on PAM4 (Pulse Amplitude Modulation Four Levels) modulation technology, digital signal processing (DSP) chip, and QSFP56 design.
The 200GBASE-FR4 QSFP56 transceiver complies with CMIS4.0, IEEE 802.3bs, QSFP MSA, and SFF-8665 standards.
The QSFPTEK 200G NVIDIA InfiniBand optical device has been 100% tested on NVIDIA InfiniBand host devices,
supporting dual Ethernet and InfiniBand HDR, and is highly suitable for end-to-end InfiniBand HDR systems. It is used in the QM8700 switch.
In addition to Mellanox MMS1W50-HM , Liyuan Tech supply a wide range of other Optical transceiver transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
