Mellanox MMS1V70-CM
- Product description: Mellanox MMS1V70-CM _100GBASE-DR QSFP28 Single Lambda 4 x 25G NRZ 1310nm 500m Duplex LC/UPC SMF Ethernet Transceiver Module_liyuan tech
-
Brand: Mellanox
Part Number: MMS1V70-CM
Form Factor: QSFP28
Max. Data Rate: 100Gbps (4x 25.78Gbps)
Wavelength: 1310nm
Max. Cable Distance: 500m
Connector: Duplex LC/UPC
Media: SMF
Transmitter Type: EML
Receiver Type: PIN
TX Power: -2.9~4dBm
Minimum Receiver Power: -5.9dBm
Power Budget: 3dB
Receiver Overload: 4dBm
Max. Power Consumption: 3.5W
Extinction Ratio: 3.5dB
DDM/DOM: Supported
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Modulation (Electrical): 4x 25G-NRZ
Modulation (Optical): 1x 100G-PAM4
CDR (Clock and Data Recovery): TX & RX Built-in CDR
Inbuilt FEC：Yes (KP4)
Bit Error Ratio (BER)： 2.4x 10-4
MTBF：12,413,304 Hours (@40°C, 60% CL)
Protocols：QSFP28 MSA, SFF-8636, IEEE 802.3cu, CAUI-4
Availability: NEW
Lead time-7days
Inventory: 200 units
Trading terms: TT wire transfer
Transportation method: Air freight
Warranty period: 180days
Country of origin: CHINA
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
Mellanox MMS1V70-CM 100GBASE-DR Single Lambda QSFP PAM4 Ethernet Optical Transceiver Module (Single Lambda, SMF, 1310nm, 500m, LC, DOM)
Mellanox MMS1V70-CM 100GBASE-DR Single Lambda QSFP optical transceiver module is designed for use in 100GBASE Ethernet throughput up to 500m over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors.
The 100 Gigabit Ethernet signal is carried over a single wavelength using onboard PAM4 modulation and FEC. The transceiver includes a Broadcom chip to convert the 4x25G NRZ electrical signals to a 1x100G PAM-4 optical signal.
Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP MSA, to allow access to real-time operating parameters. With these features, this easy to install,
hot swappable transceiver is suitable to be used in various applications, such as Data Center, 100G Ethernet.
In addition to Mellanox MMS1V70-CM , Liyuan Tech supply a wide range of other Mellanox series . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
