Mellanox MMA1B00-B150D
- Product description: Mellanox MMA1B00-B150D _40GbE Transceiver, QSFP+, MPO, 850nm_liyuan tech
-
Brand: Mellanox
Part Number: MMA1B00-B150D
Interface: QSFP+
Data Rate : 40GB
Connector Type: MPO
Wavelength: 850 nm
Maximum Distance: 150M
Transceiver Type: SR4 (Short Reach 4)
Digital Diagnostics Monitoring Interface (DDMI): Supported
Operating Temperature: 0°C to 70°C
Power Consumption : 3.5W Max
Form Factor: Pluggable
Compliance: RoHS, CE
Transmission Medium: Multimode Fiber
Hot-Swappable: Yes
MTBF: >5 Million Hours
Bit Error Rate (BER): < 10^12
Host Interface: Serial EEPROM
Management Protocol: SFF-8436
Product Features
Supports 40GbE speed for high data throughput.
Operates over multi-mode fiber up to a distance of 150 meters.
850nm wavelength for optimized data transmission.
Features MPO connectors for ease of installation.
Digital Diagnostics Monitoring Interface (DDMI) for real-time monitoring.
Product Applications
Data Center Interconnect: Ideal for connecting servers within data centers at high speeds.
Telecommunications: Suitable for high-capacity communication networks.
Enterprise Networks: Used in enterprise-level networks to ensure robust data transmission.
Multi-Mode Fiber Patch Cable: FPC-MM-OM3-2M
Mechanical Splice: SP-M1-BIM
MPO Cleaning Kit: MPO-CK
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: Thailand
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
Mellanox MMA1B00-B150D Overview
The Mellanox MMA1B00-B150D is a high-performance transceiver designed for telecommunications and data communication applications.
This QSFP+ module supports 40 Gigabit Ethernet speeds, features an MPO connector, and operates at a wavelength of 850nm. It offers impressive data transmission over multi-mode fiber,
with a maximum reach of up to 150 meters. The built-in Digital Diagnostics Monitoring Interface (DDMI) provides real-time monitoring of operation parameters.
In addition to Mellanox MMA1B00-B150D , Liyuan Tech supply a wide range of other Mellanox series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
