Mellanox MCX631432AN-ADAB
- Product description: Mellanox MCX631432AN-ADAB _ConnectX-6 Lx EN Adapter Card, Dual-port SFP28/25GbE OCP3.0/PCIe 4.0 x8_liyuan tech
-
Brand: Mellanox
Part Number: MCX631432AN-ADAB
Product Name: ConnectX-6 Lx EN adapter card
Network Connectivity: 25GbE
Form Factor: OCP3.0
Host Management: Yes
Port Count: Dual-port
Port Type: SFP28
Interface: PCIe 4.0 x8
Cryptographic Capabilities: None
Bracket Type: Thumbscrew (Pull Tab)
Maximum Data Rate : 25 Gbps per port
Operating Temperature Range: 0°C to 55°C
Storage Temperature Range: -40°C to 85°C
Relative Humidity: 5% to 95% non-condensing
Power Consumption :10W (typical)
Regulatory Compliance: RoHS, CE, FCC
Supported Operating Systems: Various Linux distributions, Windows Server
RoHS Compliant: Yes
MTBF: Over 2 million hours
Product Highlights
ConnectX-6 Lx EN Adapter
25GbE OCP3.0
Dual-port SFP28
PCIe 4.0 x8
Host management
Product Application Scenarios
High-performance computing environments
Data center networking
Enterprise cloud deployments
MSA28-T: 25GbE SFP28 transceiver module
CAB-ACC-8026S: SFP28 Direct Attached Copper Cable
OM4-Fiber-10M: 10M OM4 Fiber Optic Cable
Mellanox MCX631432AN-ADAB Overview
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: MY
Operating Temperature: 0 to 70°C
Delivery will be made within one week after placing the order.
The Mellanox MCX631432AN-ADAB ConnectX-6 Lx EN adapter card is an advanced solution offering 25GbE OCP3.0 with dual-port SFP28 and PCIe 4.0 x8 compatibility.
Designed for enhanced networking performance, it is targeted at data centers and high-performance computing environments requiring efficient host management and robust networking capabilities.
In addition to Mellanox MCX631432AN-ADAB , Liyuan Tech supply a wide range of other Mellanox series transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
