Liyuan Tech OSFP224-1.6T-2XDR4 OSFP224-1.6T-2XDR8
- Product description: Liyuan Tech OSFP224-1.6T-2XDR4 OSFP224-1.6T-2XDR8 _Customization 1.6TBASE-2xDR4 OSFP IHS/Closed Finned Top 8x200G PAM4 1310nm 500m SMF DOM Dual MPO-12/APC Linear-drive Receive Optics (LRO) Transceive
-
Brand name: Liyuan Tech
Part Number: OSFP224-1.6T-2XDR4 OSFP224-1.6T-2XDR8
Form Factor: OSFP224
Distance: 500m
Wavelength: 1310nm
Connector: Dual MPO-12/APC
Power Consumption: ≤17W
Transmitter: 1310nm Laser
Receiver: PIN + TIA
Media: SMF
Modulation（electrical): 8x212Gb/s PAM4
Modulation（Optical）: Two ports 4x212Gb/s PAM4
Case Temperature(℃): 15 to 70°C (59 to 158°F)
Protocol: 1.6T Ethernet Compliant
Built with Broadcom's 5nm DSP chip, with a maximum power consumption of 30W
The maximum total throughput is 1600Gbps
8×200G-PAM4 electrical interface converts to dual 4×200G-PAM4 optical parallel
Suitable for high-performance computing (HPC) and machine learning (ML) architectures
Compliant with OSFP multi-source protocol, IEEE 802.3dj D1p3, RoHS and Class 1 laser safety standards, supporting DDM
Availability: NEW
Lead time-7days
Trading terms: TT wire transfer
Warranty period: one year
Country of origin: CHINA
Delivery will be made within one week after placing the order.
Customized production of 1.6T optical modules for customers.
liyuan tech Customization 1.6TBASE-2xDR4 OSFP IHS/Closed Finned Top 8x200G PAM4 1310nm 500m SMF DOM Dual MPO-12/APC Linear-drive Receive Optics (LRO) Transceiver Module.
This optical module is a 1.6T 2x 800Gb/s dual-port OSFP RHS/flat-top type, featuring 2x DR4/DR8 single-mode parallel 8-channel optical module. It adopts two 2-core,
4-channel MPO-12/APC optical connectors, with each port operating at a rate of 800Gb/s. The parallel single-mode short-distance 8-channel (2x DR4/DR8) uses 200G-PAM4 modulation and employs 8-core single-mode fiber,
with a maximum transmission distance of up to 500 meters. This product is an ideal choice for supercomputing and high-performance computing (HPC) industries,
and can be seamlessly integrated into computing and storage infrastructure to ensure efficient high-performance interconnection. The RHS/flat-top version is suitable for liquid-cooled switches.
In addition to Liyuan Tech OSFP224-1.6T-2XDR4 OSFP224-1.6T-2XDR8 , Liyuan Tech has a wide range of other Innolight optical transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
