Huawei NE20E-M2F

Product description: Huawei NE20E-M2F _Chassis with 4x10GE SFP+ and 40xGE SFP fixed ports, 2xAC power module_liyuan tech
INQUIRY

Manufacturer: HUAWEI
Part Number : NE20E-M2F
Description
Huawei NE20E-M2F Chassis with 4x10GE SFP+ and 40xGE SFP fixed ports, 2xAC power module.
2 PIC slots, 2U.
Switching Capacity: 320 Gbit/s.
Forwarding Performance: 150 Mpps.
Supports E1/CE1, POS, CPOS, GE, 10GE.
NetEngine20E-M2F Integrated Service Router (NE20E-M2F) series are high-end network products developed by Huawei for transportation, finance, electricity,
government, education, and enterprise networks. They mainly serve as core nodes on small and medium-sized enterprise networks,
edge nodes on campus networks, and access nodes on small and medium-sized education networks.
Switching Capacity(Gbit/s): 320
Forwarding Performance(Mpps): 150
Number of Slots: 2 PICs
Interface Types: 10GE, GE/FE, OC-3c/STM-1c POS, OC-12c/STM-4c POS, Channelized OC-3/STM-1 POS, E1/CE1
Clock Synchronization: Synchronous Ethernet and IEEE 1588v2
Layer 2 Features: IEEE 802.1q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1ab, and STP/RSTP/MSTP
IPv4/IPv6 Routing Protocols: IPv4 static routes and dynamic routing protocols, such as RIP, OSPF, IS-IS, and BGP
IPv4/IPv6 dual stack, Various IPv4-to-IPv6 transition technologies: Manual tunnel, 6to4 tunnel, and 6PE
IPv6 static routes and dynamic routing protocols, such as BGP4+, RIPng, OSPFv3, and IS-ISv6
IPv6 neighbor discovery, PMTU discovery, TCP6, ping IPv6, tracert IPv6, socket IPv6, and IPv6 policy-based routing
L2/L3 VPN: LDP over TE, VPLS, H-VPLS, and VPN policy-based routing, Martini MPLS L2VPN, VLL/VPLS accessing L3VPN,MPLS/BGP L3 VPN and inter-AS VPN
Multicast: IGMP v1/v2/v3, IGMP snooping, IPv6 multicast, static multicast routing, PIM-SM, PIM-SSM, MBGP, and NG MVPN
QoS: WRED, five-level HQoS, and VLL/PWE3 QoS
Reliability: Smooth restart of GR: BGP/OSPF/ISIS/LDP/VLL/VPLS/RSVP/L3VPN/PIM
BFD fast detection: Static Route/Fast Reroute/VRRP/ISIS/OSPF/BGP/PIM/LSP/IPv6
Fast convergence of BGP/IGP/multicast routes
IP/LDP FRR, TE FRR, VPN FRR, and VLL FRR
Ethernet OAM, Y.1731, PWE3 end-to-end protection
Software hot patch technology to achieve software smooth upgrade
Hot swapping of components such as boards, power supplies, and fan frames
Security: ACL-based packet filtering, AAA, SNMPv3 encryption and authentication, URPF,
GTSM, DHCP snooping, ARP attack defense, and SSHv2
Value-added Services: NAT, IPSec, GRE and NetStream
OAM: Y.1731, IP FPM, MPLS OAM, 802.1ag, and 802.3ah
Operating Temperature: 0°C to 45°C
Operating Humidity: 5% RH to 85% RH, non-condensing
Operating Altitude(m): ≤ 3,000
Power Consumption (in full configuration)(W): 220
Dimensions(mm): 89 (H) x 442 (W) x 220 (D)
Full Configuration Weight(kg): 9
In addition to Huawei NE20E-M2F , Liyuan Tech supply a wide range of other HUAWEI transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
