Optical transceiver
DELL Q28-100G-SR4-G2
- Product description: DELL Q28-100G-SR4-G2 _100GbE QSFP28 SR4 MPO 850nm MMF 100m_liyuan tech
-
Manufacturer: DELL
Part number: Q28-100G-SR4-G2
Part Number: 014NV5
MPN: AFBR-89CTDZ-FT1
Device Type: Plug-in module
Form Factor: QSFP28
Max Data Rate: 100GB
Wavelength: 850nm
Max Cable Distance: 100m
Connector: MTP/MPO-12
Cable Type: MMF
Transmitter Type: VCSEL 850nm
Receiver Type: PIN
DDM/DOM: Supported
Compatibility
This Dell 014NV5 Q28-100G-SR4-G2 is compatible with the following systems:
Dell EMC PowerSwitch Z9264F-ON
Dell EMC PowerSwitch Z9332F-ON
Dell EMC PowerSwitch Z9432F-ON
Dell Networking S5212F-ON
Dell Networking S5224F-ON
Dell Networking S5232F-ON
Dell Networking S5248F-ON
Dell Networking S5296F-ON
Availability: Used
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: CHINA
Operating Temperature: 0 to 70°C
The Dell 014NV5 Q28-100G-SR4-G2 QSFP28 transceiver delivers fiber connectivity to extend the range of your network.
This hot-pluggable transceiver with QSFP28 (Quad Form Factor Pluggable) footprint features a MPO-12 connector.
The Dell networking 100GbE-SR4 QSFP28 transceiver provides 100GbE connectivity up to 100 m .
Additionally, it provides a unique enhanced digital diagnostic monitoring interface,
which allows real-time access to device operating parameters such as transceiver temperature,
laser bias current, transmitted optical power, received optical power, and transceiver supply voltage.
In addition to DELL Q28-100G-SR4-G2 , Liyuan Tech supply a wide range of other Optical transceiver transceivers. If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
∷
