Optical transceiver

Cisco CPAK-100G-LR4 Transceiver Module

Product description: Cisco CPAK-100G-LR4 module is mainly applied to support 100Gbps optical links over standard Single-Mode Fiber (SMF, G.652) terminated with SC connectors or LC connectors.
INQUIRY

Technical Parameters

Brand: Cisco

Product Family: Cisco CPAK Module

Model: CPAK-100G-LR4

Wavelength (nm): 1310nm

Cable Type: SMF Duplex

Core Size (Microns): 9-micron core SMF per G.652

Cable Distance: 10km

Primary application: support 100Gbps optical links over standard Single-Mode Fiber (SMF, G.652) terminated with SC connectors or LC connectors.

Supported Mode(s):1*100G

Supported Protocol(s):

IEEE 802.3ba

ITU OTU4

Description

The LR4 module is IEEE 802.3ba-compliant and supports link lengths of up to 10 km over standard SMF, G.652. It delivers an aggregate data signal of 100 Gbps, carried over four LAN Wavelength-Division Multiplexing (WDM) wavelengths operating at a nominal 25 Gbps per lane. Optical multiplexing and demultiplexing of the four wavelengths are managed within the module.
