Ciena 180-3530-900

Product description: Ciena 180-3530-900 _WaveLogic 5 nano-scale QSFP-DD 400ZR basic type 4x100GbE transceivers_liyuan tech
INQUIRY

Manufacturer: Ciena
Part number: 180-3530-900
CLEI: WMOTC08FAA
Form Factor: QSFP-DD
Max. Data Rate: 400Gbps
Wavelength: 1528.58~1567.54nm
Max. Cable Distance: 120km
Connector: Duplex LC
Media: SMF
TX Power: -13~-9dBm
RX Power: ＜1.5dB ROSNR penalty: -12~-6dBm ＜0.5dB ROSNR penalty: -6~5dBm
Max. Power Consumption: ≤17W
Minimum Receiver Power: ≤-14dBm
DDM/DOM: Supported
Commercial Temperature Range: 0℃ to 75°C
Inbuilt FEC: CFEC
Modulation Format: DP-16QAM
CD Robustness: 2400(ps/nm)
OSNR Tolerance: 26dB/0.1nm
Protocols: OIF 400ZR, OIF-CMIS-05.2, OIF-C-CMIS-01.2, QSFP-DD-Hardware-Rev6.3, IEEE Std 802.3-2018
Application: Edge DCI
Availability: Used
Lead time-7days
Trading terms: TT wire transfer
Warranty period: 180days
Country of origin: MY
Ciena 180-3530-900 400G DWDM tunable QSFP-DD transceiver module (SMF, 1528.77 - 1567.13 GHz, ≤ 120 km, LC/UPC, DOM)
The Ciena 180-3530-900 QSFP-DD DCO transceiver achieves EDFA through single-mode fiber (SMF) via LC/UPC connectors, with a maximum distance of up to 120 km and a throughput of 400GBASE-ZR.
This module complies with the OIF MSA standard and achieves multi-vendor interoperability, supporting interoperability with other compliant components and rapid deployment. It can operate within a temperature range of 0 to 70°C.
It also supports digital optical monitoring (DOM), allowing access to real-time parameters. Using C-FEC and 16QAM modulation, this module supports 400G tunable DWDM transmission per wavelength.
The unamplified coverage distance can reach up to 40 km, and the amplified coverage distance can reach up to 120 km. It is intended for use in access, edge,
core and data center applications, supporting an open and interoperable network ecosystem.
In addition to Ciena 180-3530-900 , Liyuan Tech supply a wide range of other Ciena Series . If you have any need or interest, please feel free to send inquiry to global@chn-liyuan.com
